Click the hotspots on the image for more information

WeldPlas Pro
Mild steel frame, integral water bed or zoned fume extraction.
Stepper motors coupled to planetary gearboxes.
10mm waterjet cut aluminium sides.
Main drives mounted on twin linear slides with pneumatic springs.
Fully automatic Z axis with plate find, arc voltage control and laser alignment.
Text to go here.
Magnetic torch breakaway.
Compact design with linear sides throughout and a laser cut mild steel beam.
Curved slats minimise plate movement.
Designed and manufactured in Britain.
Horizontal Line

WeldPlas Pro

From £16,000

(+VAT)
Brand:Weldplas
SKU:SKU0000000
Availability:Typically Ships In 3 Weeks
Configure your machine

Product Description

The Weldplas Pro is a compact plasma profiling machine, suitable for all your everyday CNC cutting needs. It is a great addition to any fabrication workshop, with a fast cutting speed of up to 15,000mm/minute. This CNC plasma cutter machine is ideal for prototyping, small batch production and general fabrication.

The Weldplas Pro can plasma cut from 3mm to 15mm thick. It comes with the powerful and easy-to-use Techserv CNC software. With advanced motion control and a wide range of standard shapes, it makes profile cutting simple.

CNC Machine Specs

Maximum Speed: 15,000mm/minute
Interface: Touch Screen
Screen Display Size: 350mm x 190mm
WiFi: Yes
Computer/Interface Ports: 4x USBs, ethernet
Frame Material: Mild steel and aluminium with linear slides mounted to the bed
Number of Axis:4
Control System: TechServ CNC system

Cutting Bed Size: 1.5m x 1.5m
  • Machine size: 2.1m x 2.2m
  • Maximum Cutting Size: 1.5m x 1.5m
  • Machine Weight: 450kg
  • Maximum Load Weight: 500kg

Plasma Pack Specs

Plasma Sound PC 50/M Art.326

Plasma Pack Dimensions (W x L x H): 286 x 590 x 406mm

Plasma Pack Weight: 23kg

Phase: Single Phase

Power Supply: 230v 50/60 Hz +/-10%

Fuse Rating (Slow Blow): 32 A

Input Power:

7.8 kVA – 40%

5.8kVA – 60%

5.3kVA – 100%

Current Adjustment Range: 20A ÷ 50A

Duty Cycle (10 min. 40°C) According to IEC 60974-1:

50 A – 40%

42 A – 60%

33 A – 100%

Stepless Regulation: Electronic

Air Consumption: 210 1/min – 5.5 bar

Protection Class: IP23 S

Maximum Edge Start Cut: 25 mm

Consumables:

  • Swirl Ring
  • Electrode
  • Nozzle
  • Retaining Cap
  • Shield Cap
  • Gas
Maximum Thickness Recommended Cutting Speed @ 5 mm Precision Cut Speed @ 5 mm Pierce Capacity
Mild Steel 25 mm 2.3 m/min 1.8 m/min 12mm
Stainless Steel 20 mm 1.5 m/min 1.1 m/min 10 mm
Aluminium 20 mm 3.2 mm/min 2.9 m/min 10 mm
Cebora iQC 110 T

Plasma Pack Dimensions (W x L x H): 232 x 562 x 477 mm

Plasma Pack Weight: 34.5 kg

Phase: Three Phase

Power Supply: 440v 50 Hz +/-10%

Fuse Rating (Slow Blow): 32A I1eff – The “effective input current” is typically shown on the machine data plate, with the symbol I1eff. If a machine has I1eff rating of 10A or less, it can be fitted with a 10A plug. If a machine has I1eff rating of more than 10A & up to 15A, then it should be fitted with a 15A plug.

Max Input Power: 20 kVA +/-10%

Current Adjustment Range: 10A ÷ 110A

Duty Cycle (10 min. 40°C) According to IEC 60974-1: 90 A – 100%

Stepless Regulation: Electronic

Protection Class: IP21 S

Maximum Edge Start Cut: 50 mm

Consumables:

  • Swirl Ring
  • Electrode
  • Nozzle
  • Retaining Cap
  • Shield Cap
  • Gas



Maximum Thickness Precision Cut Speed @ 20 mm Pierce Capacity
Mild Steel 50 mm 2.0 m/min 20 mm
Stainless Steel 40 mm 2.0 mm/min 20 mm
Aluminium 40 mm 2.8 m/min 20 mm
Cebora iQC130T Art.603

Plasma Pack Dimensions (W x L x H): 316 x 708 x 555mm

Plasma Pack Weight: 50kg

Phase: Three Phase

Power Supply: 400-440v 50/60 Hz +/-10%

Fuse Rating (Slow Blow): 32 A 25 A

  • I1eff – The “effective input current” is typically shown on the machine data plate, with the symbol I1eff. If a machine has I1eff rating of 10A or less, it can be fitted with a 10A plug. If a machine has I1eff rating of more than 10A & up to 15A, then it should be fitted with a 15A plug.

Input Power:

22kVA – 60%

17kVA – 100%

Current Adjustment Range: 10A ÷ 130A

Duty Cycle (10 min. 40°C) According to IEC 60974-1:

130 A – 60%

105 A – 100%

Stepless Regulation: Electronic

Air Consumption: 295 l/min – 6.0 bar

Protection Class: IP23 S

Maximum Edge Start Cut: 60 mm

Consumables:

  • Swirl Ring
  • Electrode
  • Nozzle
  • Retaining Cap
  • Shield Cap
  • Gas
Maximum Thickness Recommended Cutting Speed @ 10 mm Precision Cut Speed @ 10 mm Pierce Capacity
Mild Steel 60 mm 3.1 m/min 2.3 m/min 30 mm
Stainless Steel 50 mm 2.4 m/min 3.3 m/min 20 mm
Aluminium 50 mm 2.6 m/min 3.3 m/min 20 mm



Powermax 45 Sync

Plasma Pack Dimensions (W x L x H):442 x 173 x 357 mm

Plasma Pack Weight: 15 kg

Phase: Single Phase and Three Phase

Power Supply: 230v /50 Hz  33A and 400v 3PH 10A

Fuse Rating (Slow Blow): 35 A Max Input Power With CP 455G:

Current Adjustment Range: 9A ÷ 45A

Duty Cycle (10 min. 40°C) According to IEC 60974-1: 45 A – 50%

Stepless Regulation: Electronic

Protection Class: IP21 S

Maximum Edge Start Cut: 20 mm

Consumables:

  • Sync Cartridge



Maximum Thickness Precision Cut Speed @ 6 mm Pierce Capacity
Mild Steel 20 mm 1390 m/min 12 mm
Stainless Steel 20 mm 900 mm/min 12 mm
Aluminium 20 mm 2050 m/min 10 mm
Powermax 65 Sync

Plasma Pack Dimensions (W x L x H):483 x 233 x 430 mm

Plasma Pack Weight: 24.1 kg

Phase: Three Phase

Power Supply: 400v 3PH 15.5A

Fuse Rating (Slow Blow): 20 A Max Input Power With CP 455G:

Current Adjustment Range: 20A ÷ 65A

Duty Cycle (10 min. 40°C) According to IEC 60974-1: 65 A – 50%

Stepless Regulation: Electronic

Protection Class: IP21 S

Maximum Edge Start Cut: 25 mm

Consumables:

  • Sync Cartridge



Maximum Thickness Precision Cut Speed @ 6 mm Pierce Capacity
Mild Steel 25 mm 2570 m/min 16 mm
Stainless Steel 20 mm 2440 mm/min 12 mm
Aluminium 20 mm 2900 m/min 12 mm

Powermax 85 Sync

Plasma Pack Dimensions (W x L x H):483 x 233 x 430 mm

Plasma Pack Weight: 23.5 kg

Phase: Three Phase

Power Supply: 400v 3PH 20.5A

Fuse Rating (Slow Blow): 25 A Max Input Power With CP 455G:

Current Adjustment Range: 25A ÷ 85A

Duty Cycle (10 min. 40°C) According to IEC 60974-1: 85 A – 60%

Stepless Regulation: Electronic

Protection Class: IP21 S

Maximum Edge Start Cut: 30 mm

Consumables:

  • Sync Cartridge



Maximum Thickness Precision Cut Speed @ 6 mm Pierce Capacity
Mild Steel 30 mm 3560 m/min 20 mm
Stainless Steel 25 mm 3630 mm/min 16 mm
Aluminium 25 mm 3630 m/min 16 mm



Powermax 105 Sync

Plasma Pack Dimensions (W x L x H):592 x 274 x 508 mm

Plasma Pack Weight: 45 kg

Phase: Three Phase

Power Supply: 400v 3PH 30A

Fuse Rating (Slow Blow): 35 A

Max Input Power With CP 455G:

Current Adjustment Range: 30A ÷ 105A

Duty Cycle (10 min. 40°C) According to IEC 60974-1: 105 A – 80%

Stepless Regulation: Electronic

Protection Class: IP21 S

Maximum Edge Start Cut: 40 mm

Consumables:

  • Sync Cartridge



Maximum Thickness Precision Cut Speed @ 6 mm Pierce Capacity
Mild Steel 40 mm 3960 m/min 22 mm
Stainless Steel 32 mm 4700 mm/min 20 mm
Aluminium 32 mm 5660 m/min 20 mm

Machine Setup and Safety

  • Setup
    • Our engineers will assess the power requirements for your machine. They will specify which services are required and their locations.
    • The WeldPlas Pro is shipped fully assembled. For installation, simply plug in the machine’s plasma pack and power supply, then connect the compressed air and fill the waterbed or connect the extraction.
    • A Weldfast engineer will take you through the safety features of the machine and train your operators, so they can safely operate the machine and get the best out of it. Once our engineer has completed the final calibration checks, you can then sign off the machine.
    • If required, an engineer will make a second visit to continue the operator training and demonstrate the software’s advanced features.



  • Software
    • The Techserv CNC software is designed specifically for profile cutting and is fitted to all our new machines as standard
    • File types accepted: Essi, Word address, NC ( Strucad) DXF and many others
    • Nesting: Array and true shape nesting built in
    • Wide range of standard shapes including rings, flanges and blanks
    • Customisable shapes with save and edit facility
    • Optional line following scanner for drawn shapes
    • Multi-axis 64 bit motion control
    • Position accuracy +/- 0.01 mm
    • Full circular interpolation axis control
    • Built-in magnetic breakaway for collision control



  • Safety
    • Machine mounted emergency stop buttons for operator safety
    • Waterbed fume control

Warranty

Servicing

  • Maintenance contracts are available at 3, 6 or 12 month intervals.
  • We have a team of dedicated service engineers for repairs and maintenance. We can also fix some issues remotely.
  • We hold a comprehensive range of spare parts in the UK and most are dispatched the same day.
  • We regularly update our CNC system. Software upgrades are available online or can be installed by our trained engineers.
