Click the hotspots on the image for more information

WeldPlas
100mm steel box section frame.
Stepper motors coupled to planetary gearboxes.
150mm and 100m laser cut steel box section.
Main drives mounted on twin linear slides with pneumatic springs.
Vertically mounted rack, protected from contamination.
Magnetic torch breakaway.
Heavy duty aluminium extruded beam.
Curved slats minimise plate movement.
Designed and manufactured in Britain.
Horizontal Line

WeldPlas

From £16,000

(+VAT)
Brand:Weldplas
SKU:SKU0000000
Availability:Typically Ships In 3 Weeks
Configure your machine

Product Description

The Weldplas CNC cutting table is a versatile plasma and gas machine that is ideal for everyday industrial plasma cutting.

The Weldplas can plasma cut from 1mm to 25mm thick. This is increased up to 150mm thick for mild steel when the CNC machine is fitted with an optional gas cutting head. It can be paired with single phase or three phase plasma packs, and the integral watertray provides an effective method of fume capture.

Setting up a gas cutting head can be challenging for new operators so our automatic system uses a proportional gas pressure valve to adjust the preheat and cut oxygen pressure. The system will automatically set the preheat time and pressure with a teachable facility for use with a cold or hot plate. The system will perform a cut ramp on thicker steel, gradually increasing the pressure and speed of the cut during the pierce cycle. This reduces the risk of blowback blocking the cutting nozzle.

The separate cutting bed can be floor mounted to give the maximum versatility for any CNC machine. The bed can be adapted to suit many cutting applications, such as cutting very thick slab material or positioning a digger bucket directly under the machine for cutting. In addition, a modified bed can be fitted to allow the cutting of large box sections.

Its heavy-duty box section frame and mild steel rails make the Weldplas a robust plasma and gas cutting machine. It’s suitable for the harshest of environments, including heavy fabrication shops, shipyards and steel mills.

CNC Machine Specs

Maximum Cutting Speed: 12,000mm/minute
Interface: Touch Screen
Screen Display Size: 350mm x 190mm
WiFi: Yes
Computer/Interface Ports: 4x USBs, ethernet
Frame Material: Mild steel box section with floor-mounted heavy-duty mild steel rails
Number of Axis: 4
Control System: TechServ CNC system

Cutting Bed Size: 1.5m x 1.5m
  • Machine size: 2.4m x 2.2m
  • Maximum Cutting Size :1.5m x 1.5m
  • Machine Weight: 350kg
  • Maximum Load Weight: 1.5 tonnes
Cutting Bed Size: 1.5m x 3m
  • Machine size: 2.4m x 3.7m
  • Maximum Cutting Size: 1.5m x 3m
  • Machine Weight: 400kg
  • Maximum Load Weight: 1.5 tonnes
Cutting Bed Size: 1.5m x 6m
  • Machine size:  2.4m x 6.7m
  • Maximum Cutting Size: 1.5m x 6m
  • Machine Weight: 450kg
  • Maximum Load Weight: 1.5 tonnes

Plasma Pack Specs

Plasma Sound PC 50/M Art.326

Plasma Pack Dimensions (W x L x H): 286 x 590 x 406mm

Plasma Pack Weight: 23kg

Phase: Single Phase

Power Supply: 230v 50/60 Hz +/-10%

Fuse Rating (Slow Blow): 32 A

Input Power:

7.8 kVA – 40%

5.8kVA – 60%

5.3kVA – 100%

Current Adjustment Range: 20A ÷ 50A

Duty Cycle (10 min. 40°C) According to IEC 60974-1:

50 A – 40%

42 A – 60%

33 A – 100%

Stepless Regulation: Electronic

Air Consumption: 210 1/min – 5.5 bar

Protection Class: IP23 S

Maximum Edge Start Cut: 25 mm

Consumables:

  • Swirl Ring
  • Electrode
  • Nozzle
  • Retaining Cap
  • Shield Cap
  • Gas
Maximum Thickness Recommended Cutting Speed @ 5 mm Precision Cut Speed @ 5 mm Pierce Capacity
Mild Steel 25 mm 2.3 m/min 1.8 m/min 12mm
Stainless Steel 20 mm 1.5 m/min 1.1 m/min 10 mm
Aluminium 20 mm 3.2 mm/min 2.9 m/min 10 mm

Plasma Pack Dimensions (W x L x H): 232 x 562 x 477 mm

Plasma Pack Weight: 24.5kg

Phase: Three Phase

Power Supply: 440v 50 Hz +/-10%

Fuse Rating (Slow Blow): 16A I1eff – The “effective input current” is typically shown on the machine data plate, with the symbol I1eff. If a machine has I1eff rating of 10A or less, it can be fitted with a 10A plug. If a machine has I1eff rating of more than 10A & up to 15A, then it should be fitted with a 15A plug.

Max Input Power : 9.7 kVA +/-10%

Current Adjustment Range: 10A ÷ 70A

Duty Cycle (10 min. 40°C) According to IEC 60974-1: 70 A – 70%

Stepless Regulation: Electronic

Protection Class: IP21 S

Maximum Edge Start Cut: 35 mm

Consumables:

  • Swirl Ring
  • Electrode
  • Nozzle
  • Retaining Cap
  • Shield Cap
  • Gas



Maximum Thickness Precision Cut Speed @ 10 mm Pierce Capacity
Mild Steel 35 mm 1.4 m/min 15 mm
Stainless Steel 25 mm 0.8 mm/min 12 mm
Aluminium 25 mm 1.3 m/min 12 mm
Cebora iQC 110 T

Plasma Pack Dimensions (W x L x H): 232 x 562 x 477 mm

Plasma Pack Weight: 34.5 kg

Phase: Three Phase

Power Supply: 440v 50 Hz +/-10%

Fuse Rating (Slow Blow): 32A I1eff – The “effective input current” is typically shown on the machine data plate, with the symbol I1eff. If a machine has I1eff rating of 10A or less, it can be fitted with a 10A plug. If a machine has I1eff rating of more than 10A & up to 15A, then it should be fitted with a 15A plug.

Max Input Power: 20 kVA +/-10%

Current Adjustment Range: 10A ÷ 110A

Duty Cycle (10 min. 40°C) According to IEC 60974-1: 90 A – 100%

Stepless Regulation: Electronic

Protection Class: IP21 S

Maximum Edge Start Cut: 50 mm

Consumables:

  • Swirl Ring
  • Electrode
  • Nozzle
  • Retaining Cap
  • Shield Cap
  • Gas



Maximum Thickness Precision Cut Speed @ 20 mm Pierce Capacity
Mild Steel 50 mm 2.0 m/min 20 mm
Stainless Steel 40 mm 2.0 mm/min 20 mm
Aluminium 40 mm 2.8 m/min 20 mm
Cebora iQC130T Art.603

Plasma Pack Dimensions (W x L x H): 316 x 708 x 555mm

Plasma Pack Weight: 50kg

Phase: Three Phase

Power Supply: 400-440v 50/60 Hz +/-10%

Fuse Rating (Slow Blow): 32 A 25 A

  • I1eff – The “effective input current” is typically shown on the machine data plate, with the symbol I1eff. If a machine has I1eff rating of 10A or less, it can be fitted with a 10A plug. If a machine has I1eff rating of more than 10A & up to 15A, then it should be fitted with a 15A plug.

Input Power:

22kVA – 60%

17kVA – 100%

Current Adjustment Range: 10A ÷ 130A

Duty Cycle (10 min. 40°C) According to IEC 60974-1:

130 A – 60%

105 A – 100%

Stepless Regulation: Electronic

Air Consumption: 295 l/min – 6.0 bar

Protection Class: IP23 S

Maximum Edge Start Cut: 60 mm

Consumables:

  • Swirl Ring
  • Electrode
  • Nozzle
  • Retaining Cap
  • Shield Cap
  • Gas
Maximum Thickness Recommended Cutting Speed @ 10 mm Precision Cut Speed @ 10 mm Pierce Capacity
Mild Steel 60 mm 3.1 m/min 2.3 m/min 30 mm
Stainless Steel 50 mm 2.4 m/min 3.3 m/min 20 mm
Aluminium 50 mm 2.6 m/min 3.3 m/min 20 mm



Powermax 45 Sync

Plasma Pack Dimensions (W x L x H):442 x 173 x 357 mm

Plasma Pack Weight: 15 kg

Phase: Single Phase and Three Phase

Power Supply: 230v /50 Hz  33A and 400v 3PH 10A

Fuse Rating (Slow Blow): 35 A Max Input Power With CP 455G:

Current Adjustment Range: 9A ÷ 45A

Duty Cycle (10 min. 40°C) According to IEC 60974-1: 45 A – 50%

Stepless Regulation: Electronic

Protection Class: IP21 S

Maximum Edge Start Cut: 20 mm

Consumables:

  • Sync Cartridge



Maximum Thickness Precision Cut Speed @ 6 mm Pierce Capacity
Mild Steel 20 mm 1390 m/min 12 mm
Stainless Steel 20 mm 900 mm/min 12 mm
Aluminium 20 mm 2050 m/min 10 mm
Powermax 65 Sync

Plasma Pack Dimensions (W x L x H):483 x 233 x 430 mm

Plasma Pack Weight: 24.1 kg

Phase: Three Phase

Power Supply: 400v 3PH 15.5A

Fuse Rating (Slow Blow): 20 A Max Input Power With CP 455G:

Current Adjustment Range: 20A ÷ 65A

Duty Cycle (10 min. 40°C) According to IEC 60974-1: 65 A – 50%

Stepless Regulation: Electronic

Protection Class: IP21 S

Maximum Edge Start Cut: 25 mm

Consumables:

  • Sync Cartridge



Maximum Thickness Precision Cut Speed @ 6 mm Pierce Capacity
Mild Steel 25 mm 2570 m/min 16 mm
Stainless Steel 20 mm 2440 mm/min 12 mm
Aluminium 20 mm 2900 m/min 12 mm

Powermax 85 Sync

Plasma Pack Dimensions (W x L x H):483 x 233 x 430 mm

Plasma Pack Weight: 23.5 kg

Phase: Three Phase

Power Supply: 400v 3PH 20.5A

Fuse Rating (Slow Blow): 25 A Max Input Power With CP 455G:

Current Adjustment Range: 25A ÷ 85A

Duty Cycle (10 min. 40°C) According to IEC 60974-1: 85 A – 60%

Stepless Regulation: Electronic

Protection Class: IP21 S

Maximum Edge Start Cut: 30 mm

Consumables:

  • Sync Cartridge



Maximum Thickness Precision Cut Speed @ 6 mm Pierce Capacity
Mild Steel 30 mm 3560 m/min 20 mm
Stainless Steel 25 mm 3630 mm/min 16 mm
Aluminium 25 mm 3630 m/min 16 mm



Powermax 105 Sync

Plasma Pack Dimensions (W x L x H):592 x 274 x 508 mm

Plasma Pack Weight: 45 kg

Phase: Three Phase

Power Supply: 400v 3PH 30A

Fuse Rating (Slow Blow): 35 A

Max Input Power With CP 455G:

Current Adjustment Range: 30A ÷ 105A

Duty Cycle (10 min. 40°C) According to IEC 60974-1: 105 A – 80%

Stepless Regulation: Electronic

Protection Class: IP21 S

Maximum Edge Start Cut: 40 mm

Consumables:

  • Sync Cartridge



Maximum Thickness Precision Cut Speed @ 6 mm Pierce Capacity
Mild Steel 40 mm 3960 m/min 22 mm
Stainless Steel 32 mm 4700 mm/min 20 mm
Aluminium 32 mm 5660 m/min 20 mm

Machine Setup and Safety

  • Setup
    • Our engineers will assess the power requirements for your machine. They will specify which services are required and their locations.
    • This WeldPlas machine is shipped with the rails disassembled. Our engineers will position the rails and bolt them to the floor. The machine is then fitted to the rails and the cutting bed is installed. After connecting the services the machine will be tested.
    • A Weldfast engineer will take you through the safety features of the machine and train your operators, so they can safely operate the machine and get the best out of it. Once our engineer has completed the final calibration checks, you can then sign off the machine.
    • If required, an engineer will make a second visit to continue the operator training and demonstrate the software’s advanced features.



  • Software
    • The Techserv CNC software is designed specifically for profile cutting and is fitted to all our new machines as standard
    • File types accepted: Essi, Word address, NC ( Strucad) DXF and many others
    • Nesting: Array and true shape nesting built in
    • Wide range of standard shapes including rings, flanges and blanks
    • Customisable shapes with save and edit facility
    • Optional line following scanner for drawn shapes
    • Multi-axis 64 bit motion control
    • Position accuracy +/- 0.01 mm
    • Full circular interpolation axis control
    • Built-in magnetic breakaway for collision control



  • Safety
    • Machine mounted emergency stop buttons for operator safety
    • Waterbed fume control

Warranty

Servicing

  • Maintenance contracts are available at 3, 6 or 12 month intervals.
  • We have a team of dedicated service engineers for repairs and maintenance. We can also fix some issues remotely.
  • We hold a comprehensive range of spare parts in the UK and most are dispatched the same day.
  • We regularly update our CNC system. Software upgrades are available online or can be installed by our trained engineers.
